Other items in the box
- AC Power Cord
- Remote Control
- VGA cable
- DVI-D cable
- Optional accessories: Base
- Optional accessories: Detachable Speakers
large display
300WN5BB/00
excellent and robust display solution
Excellent and robust, the network-controlled Philips 300WN5 LCD monitor provides a reliable and multi-function solution with Philips leading display technology that guarantees your message gets out to the public crystal clear.
See all benefitsUnfortunately this product is no longer available
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
large display
Similar products
See all Unmapped
Lifecycle is longer than plasma displays
A longer lifecycle means a lower total cost of ownership and adds up to long-term savings.
Remote Management and Configuration via RS232
Remote Management allows the user to control and adjust the displays remotely via the RS232 protocol. Using CEC commands, you are able to have full control over all the displays in your signage network at any time.
Brightness automatically adjusts with ambient conditions
The adjustment of display settings to correspond with ambient light without user intervention.
Automatic alert provides advance warning of overheating
Automatic overheat warning generates an alert and delivers it to the designated system manager when a display device's operating temperature exceeds designated levels.
Intelligent power management for lower consumption
Intelligent power management employs energy-efficient technologies in product design to reduce power consumption and significantly lower the total cost of ownership.
Hidden control buttons prevent tampering with settings
Control buttons placed at the rear of a monitor used for public display to prevent tampering with display settings.
Easy plug-and-play DVI for a true digital experience
A DVI cable is shipped with the product to provide high quality digital display.
WXGA, wide format, 1280x768 resolution for sharper display
For graphics monitors, the screen resolution signifies the number of dots (pixels) on the entire screen. WXGA provides the resolutions 1280 by 768 pixels. In addition, WXGA allows monitors to be non-interlaced. This ensures a better display performance and accurate color display effect.
Technical Specifications
-
Picture/Display
- Panel Size
- 29.53"/ 75cm
- Aspect ratio
- 15:9
- LCD panel type
-
- 1280 x 768 pixels
- Anti-glare polarizer
-
- Pixel pitch
- 0.5025 x 0.5025 mm
- Optimum resolution
- 1280 x 768 @ 60Hz
- Brightness
- 600 cd/m²
- Display colors
- 16.7 M
- Contrast ratio (typical)
- 800:1
- Response time (typical)
- 16 ms
- Viewing angle
- @ C/R > 10
- Viewing angle (horizontal)
- 170 degree
- Viewing angle (vertical)
- 170 degree
- Horizontal Scanning Frequency
- 31 - 49 kHz
- Maximum Resolution
- 1280 x 768 @ 60Hz
- Factory Preset Modes
- 4 modes
- Refresh Rate (V)
- 60 Hz
- sRGB
- Yes
- White Chromaticity, 5300K
- x = 0.328 / y = 0.344
- White Chromaticity, 6500K
- x = 0.313 / y = 0.329
- White Chromaticity, 9300K
- x = 0.283 / y = 0.297
-
Connectivity
- PC
-
- D-Sub x1
- DVI-D x1
- 3.5 mm PC audio input x1
- RS232 x1
-
- AV output
-
- 3.5 mm jack (L/R) x1
- Ext 3.5 mm jack x1
-
-
Convenience
- Plug & Play Compatibility
-
- sRGB
- Windows 98/ME/2000/XP
-
- User convenience
-
- On-screen Display
- Automatic Brightness Control
- Automatic Overheat Warning
-
- Monitor Controls
-
- Left/Right
- Menu (OK)
- Power On/Off
- Up/Down
- Input select
-
- Regulatory approvals
-
- CE Mark
- FCC-B, UL, CSA
- NUTEK, Energy Star
-
- OSD Languages
-
- English
- French
- German
- Italian
- Spanish
- Simplified Chinese
-
- VESA Mount
- 100 x 100 mm
-
Power
- Power supply
- Built-in
- Consumption (On mode)
- 130W
- Power LED indicator
-
- Operation - Blue
- Stand by/sleep - Amber
-
- Complies with
-
- Energy Star
- NUTEK
-
- Consumption (Off Mode)
- < 2 W
-
Supported Display Resolution
- Computer formats
-
- 640 x 480, 60Hz
- 800 x 600, 60Hz
- 1024 x 768, 60Hz
- 1280 x 768, 60Hz
-
-
Dimensions
- Weight
- 14 kg
- Temperature range (operation)
- 5°C to 35°C
- Temperature range (storage)
- -20°C to 60°C
- Relative humidity
- 20% - 80%
- MTBF
- 50,000 hrs
- Depth (w/o base & speakers)
- 115 mm
- Depth (with speakers)
- 183 mm
- Height (w/o base & speakers)
- 469.3 mm
- Height (with speakers)
- 505 mm
- Width (w/o base & speakers)
- 726.7 mm
- Width (with speakers)
- 867.7 mm
-
Accessories
- Included accessories
-
- AC Power Cord
- Remote Control
- VGA cable
- DVI-D cable
-
- User Manual
- Yes
- Optional accessories
-
- Base
- Detachable Speakers
-
