Avalon FM30
Fetal Monitor
Avalon FM30
Fetal Monitor
Avalon FM fetal and maternal monitors are Philips' first and only to offer automated coincidence detection (cross-channel verification) using Smart Pulse, measuring fetal & maternal heart rates separately to enhance diagnostic confidence.
Extensive fetal parameters when more information is needed
NST Trace Interpretation to improve efficiency
Smart Pulse for automated coincidence detection
Features
Extensive fetal parameters when more information is needed
For complex cases, the Avalon FM30 fetal monitor offers external and internal fetal parameters. These include ultrasound, fetal movement, direct fetal heart rate, Toco and intrauterine pressure, as well as maternal pulse rate, and ECG, with optional Sp02 and blood pressure.
IntelliSpace Perinatal connectivity for continuous care
The Avalon FM30 fetal monitor connects to IntelliSpace Perinatal, Philips obstetrical surveillance and information management system. This supports the continuum of care from the first antepartum visit to delivery, postpartum, and newborn nursery, discharge and postpartum follow-up visits.
Large, intuitive color display clearly shows status
The luminous color display has large numerics and graphs so you can easily view maternal and fetal ECG waves.
Specifications
- Battery
- Operating time (optional)
- Up to four
- General
- Care stage
- Intrapartum
- Patient type
- Fetal and maternal
- Waveforms
- Not for diagnostic use
- DECG, MECG
- Parameters
- External fetal parameters
- US/Toco
- Twin capability
- Standard
- Triplets capability
- Optional
- Internal fetal parameters
- DECG, IUP
- Smart Pulse technology
- Standard
- Cross channel verification
- Standard
- Fetal movement profile
- Standard
- Interfaces
- PS/2 interfaces
- Optional
- Interfaces
- System interface (optional)
- Serial, LAN
- Readings
- NST trace interpretation (optional)
- Up to three Fetal Heart Rates (FHR)
- NST timer
- Standard
- Data storage
- Data buffer
- Up to one
- Weight
- Weight without battery option
- 11.2 pounds/5.1 kg
- Weight with battery option
- 11.7 pounds/5.3 kg
- Display
- Monitor screen display
- 6.5 in/16.51 cm
- Touchscreen operation
- Standard
Related products
- As a caregiver, you want to sustain your patient’s mobility and comfort. Cableless transducers can help, without sacrificing essential monitoring. However, traditional cableless technology has limitations, such as mothers with a high BMI¹,² or those undergoing epidural procedures. This is where the Avalon beltless maternal and fetal monitoring solution provides an alternative.
- Avalon FM fetal and maternal monitors are Philips first and only to offer automated coincidence detection (cross-channel verification) using Smart Pulse. It measures the fetal & maternal heart rates separately to enhance diagnostic confidence.
- The FM50 is intended for more complex antepartum and intrapartum cases and measures fetal heart rate (including noninvasive triplet monitoring), provides alarms, and supports direct fetal ECG. Maternal parameters include toco, intrauterine pressure, blood pressure, pulse rate, pulse oximetry, ECG, an alternative form factor, two dedicated rear tele sockets, and a VGA output for an external display.
